SIRIUS 1 HV

The versatile and robust rotating laser




The fully automatic horizontal/vertical rotating laser for clever craftsmen inclusive laser receiver ACCEPTOR 2 with digital display. It is ideal for levelling and aligning in interior outfitting and construction.

SIRIUS 1 HV combines optimum functionality, a full range of features and an attractive price-performance ratio.


Protected against low pressure jet water and dustproof in accordance with IP 65

Thanks to its ingenious seal, the SIRIUS 1 rotating laser is protected against low pressure jet water and dustproof in accordance with IP 65 and therefore meets sealing requirements expected of much more expensive rotating lasers.


Improved ruggedness

The new rotor protection made of cast aluminum and break-proof glass means the new SIRIUS 1 is extremely robust. The laser even easily withstands heavy jolts and falls.


Improved ergonomics

Thanks to the new designed rubber handle the new SIRIUS 1 sits even better in one's hand.

The rubber-covered feet ensure improved stability even on smooth surfaces.


Features

  • Fully automatic horizontal/vertical laser for interior outfitting and exterior applications
  • High-power laser diode (laser class 3R) for very good laser beam visibility
  • Alternatively available with laser class 2
  • Automatic level control stops the laser if it receives a heavy jolt. In this way, height errors are avoided.
  • Upward and downward plumb beam
  • Manual setting of slopes in 2 axes
  • Scanning function and dot mode
  • Rugged housing protected against low pressure jet water in accordance with IP 65
  • Rotor protection made of cast aluminum and break-proof glass
  • High-power NiMH rechargeable batteries for long operation
  • Remote control for a convenient handling


Applications

Ideal for use on every construction site. Perfect for levelling in applications such as:

  • Casting concrete floors
  • Meter marking in interior work
  • Dry wall construction
  • Use of batter boards
  • Laying screed
  • Masonry and excavation work
  • Landscaping
  • Interior construction


Scope of delivery

  • Rotating laser SIRIUS 1 HV
  • Laser receiver ACCEPTOR 2 digital with mm display and Heavy-Duty rod clamp
  • Remote control
  • Rechargeable batteries and charger
  • Transport case


Technical data

Accuracy ± 1 mm/10 m
Self-levelling range ± 5° motor-powered, with automatic level control
Working range Ø approx. 300 m with receiver
Laser < 5 mW, Laser class 3R, 635 nm or

< 1 mW Laser class 2, 635 nm
Rotating speed 0, 60, 120, 300 and 600 rpm
Scanning angle 0°, 6°, 20°, 50° and 90°
Protection class IP 65
Power supply NiMH rechargeable batteries 4.8 V, 3800 mAh
Operating duration approx. 30 h
Weight 2.3 kg
Dimensions (width/depth/height) 150 mm x 200 mm x 190 mm
Operating temperature -20°C to + 50°C
Connection thread 5/8''
Order Information
471945 Rotating laser SIRIUS 1 HV

Incl. laser receiver ACCEPTOR 2 digital with mm display and Heavy-Duty rod clamp, remote control, rechargeable batteries, charger and case

Laser receiver ACCEPTOR 2 digital


Technical data:
Accuracy switchable, ± 1 mm, ± 4 mm and ± 6 mm
Working range Ø 550 m (depends on laser)
Length of detectorfield 50 mm
Reception angle ± 65°
Protection class IP 67
Operation temperature -20°C to + 50°C
Power supply 2 x 1.5 V (AA) or rechargeable batteries NiMH
Operation duration up to 120 h
