Functions & key features


The fast all-rounder with Vibration Control

  • Fastest drilling rate in its class due to 1150 W motor and powerful hammer mechanism
  • SDS max comfort for easy and fast tool changes with one hand
  • Vibration Control (10 m/s² for drilling, 8 m/s² for chiseling) ensures convenient working, even in time-intensive application


TECHNICAL DATA

Performance data

Impact rate at rated speed 1,500 – 3,050 bpm
Rated speed 170 – 340 rpm


Additional data

Rated input power 1,150 W
Impact energy (according to EPTA 05/2016) 8.8 J
Weight 6.8 kg
Tool holder SDS max


Drilling range

Drilling dia. concrete, hammer drill bits 12 – 40 mm
Opt. appl. range concrete, hammer drill bits 18 – 32 mm
Drilling dia. concrete, breakthrough drill bits 45 – 55 mm
Drilling diameter in concrete with core cutters 40 – 90 mm


Total vibration values

(Hammer drilling in concrete)

Vibration emission value ah 10.5 m/s²
Uncertainty K 1.5 m/s²


Total vibration values

(Chiseling in concrete)

Vibration emission value ah 7.5 m/s²
Uncertainty K 1.5 m/s²


Hammer drilling in concrete

Vibration emission value ah 10.5 m/s²
Uncertainty K 1.5 m/s²


Chiseling in concrete

Vibration emission value ah 7.5 m/s²
Uncertainty K 1.5 m/s²

The A-rated noise level of the power tool is typically as follows: Sound pressure level 93 dB(A); Sound power level 104 dB(A). Uncertainty K= 3 dB.


GBH 5-40 DCE PROFESSIONAL: FURTHER INFORMATION

Product Highlights

The GBH 5-40 DCE Professional is uniquely designed within Bosch’s SDS max corded rotary hammer category for comfortable handling and reduced user fatigue in extensive applications. Its Vibration Control and lightweight design enable effortless and continuous work in time-intensive tasks. The rotary hammer is also built for durability, featuring robust metal components and an optimised lubrication system. Its strong motor enables the delivery of 8.8 J of impact energy for a fast drilling progress and high material removal rate.
